ZOOM 9010 4 IN / 4 OUT STUDIO PROCESSOR

CONDIZIONI ECCELLENTI

Completo di manuale istruzioni in italiano and with advanced Sound processor Operation  English  Manual

Usato da Mark Knopfler nel tour" On every streey del 91/92 "con i Dire Straits

http://www.hendrixguitars.com/Knopfler.htm

Manuale:

http://www.zoom.co.jp/archive/Previous_Model/E_9010.pdf

Electrical Characteristics Frequency Response 16 Hz - 20 kHz

Dynamic Range over 90 dB

Input Number of Channels Front 1 unbalanced (Hi-Z input)

Rear 4 balanced (CH 1 can be mixed with front panel input)

Hi-Z Input Levd -10 dBm- -40 dBm, adjustable

Input Impedance Front 470 kR (Hi-Z input)

Rear t 4 dBm, 10 kR/-20 dBm, 10 kR

Connectors Standard 114" phone jacks

Output Number of Channels 4 unbalanced

Output Impedance + 4 dBm, 3001 - 20 dBm, 300

Connectors Standard 1/4" phone jacks

AD/DA Conversion A/D Conversion 16-bit linear

D/A Conversion 16-bit linear (with 4 times over-sampling filter)

Sampling Frequency 44.1 kHz

-- -- - - -

Memory Preset Programs 60

User Programs 60 (can be increased by RAM card)

Routings 4 (can be increased by ROM card)

Effects A Type (15 programs) Reverb A, EIR A, Echo A, Chorus A, Flanger A, Phaser A,

Pitch Shifter A, Auto Wah, Equalizer A, Enhancer, Noise Gate,

Distortion, Amp Simulator, Compressor, Limiter

B Type (13 programs) Reverb 1 6, Reverb 2 B, E/R 1 B , EIR 2 B, Gate Reverb,

Echo B, Chorus B, Bend Chorus, Flanger B, Phaser B, Pitch

Shifter B, Tremolo, Equalizer B

C Type (10 programs) Chorus C, Flanger C, Phaser C, Pitch Shifter C, Equalizer C,

Echo C, Reverb 1 C. Reverb 2 C. EIR 1 C, EIR 2 C

D Type (2 programs) Reverb D, Multi Chorus

FRONT PANEL Switch POWER

Keys INPUTIFUNCTION (1, 2, 3, 4), ALT, QUICK, MODE, DIAL, STORE,

BYPASS, EXIT, EXECUTE

Dials EDIT DIAL, Hi-Z INPUT LEVEL

LEDs Patch number (7 segments x 2)

Group number (7 segments X 1)

LCD 24 characters X 2 rows (backlit)

Indicator LEDs PEAK x4, ALT, QUICK, DIAL, STORE, BYPASS, CARD, USER

Terminals Hi-Z input, CARD slot

REAR PANEL Switches Input level switch x 2, Output level switch x 2

Dial LCD contrast

Terminals INPUT (1, 2, 3, 4)) OUTPUT (1, 2, 3, 4), MlDl IN, MlDl OUT,

PEDALISW (1, 2), REMOTE

Power Supply AC 50160 Hz

OTHERS Power Consumption 25 W

Dimensions 482 (W) x 340.5 (D) X 44 (H) rnm

(19" X13-38" X 1-3/4")

EIA 14inch 1 RACK UNIT

Weight 4.5 kg (9 Ibs., 14 02.)
